Mainly used for screening copper tape of various types of cables.

Pay-off stand , well-shaped wire guiding stand, taping head, concentric type copper taping head, meter counter, caterpillar traction device, take-up and traversing stand, electronic control and safety protection device.

1、Diameter of cable before screening:         φ80mm

2、Speed of copper tape:                          189-421rpm

3、Pitch of copper tape:                               8-184mm

4、Speed of taping head:                   189-421rpm

5、Taping pitch:                 18-184mm

6、Caterpillar traction:        1250kg

7、Outlet speed:         7.58-34.79m/min

8、Main motor power:   18.5kw

9、Take-up reel stand:    PN1250-PN2500
